Two Factor Authentication is great–but what if you lose your phone or have your number hijacked?

Account hijack is a worry for anyone. What kind of chaos could someone cause simply by taking over your email or social media account? Or how about spending money on your behalf on Amazon, eBay or other online retailers?

The obvious fraud will not be long-lasting, but there is an aftermath too. Changing passwords, getting back into accounts that have been compromised and their security information changed.

In the worst cases you might lose access to an account permanently. Organisations like Google, Microsoft, Facebook or eBay, are not easy to deal with in cases where your account is thoroughly compromised. They may not be sure whether your are the victim attempting to recover an account, or the imposter attempting to compromise an account. Even getting to speak to a human can be challenging, as they rely on automated systems, and when you do, you may not get the answer you want.

The solution is stronger security so that account hijack is less common, but security is never easy. It is a system, and like any system, any change you make can impact other parts of the system. In the old world, the most common approach had three key parts, username, password and email. The username was often the email address, so perhaps make that two key parts. Lose the password, and you can reset it by email. Two problems with this approach. First, the password might be stolen or guessed (rather easy considering massive databases username/password combinations easily available online). And second, the email is security-critical, and email can be intercepted as it often travels the internet in plain text, for at least part of its journey. If you use Office 365, for example, your connection to Office 365 is encrypted, but an email sent to you may still be plain text until it arrives on Microsoft’s servers.

There is therefore a big trend towards 2-factor authentication (2FA): something you have as well as something you know. This is not new, and many of us have used things like little devices that display one-time pass codes that you use in addition to a password, such as the RSA SecureID key fob devices.


Another common approach is a card and a card reader. The card readers are all the same, and you use something like a bank card, put in your PIN, and it displays a code. An imposter would need to clone your card, or steal it and know the PIN.

in the EU, everyone is becoming familiar with 2FA thanks to the revised Payment Services Directive (PSD2) which comes into effect in September 2019 and requires Strong Customer Authentication (SCA). Details of what this means in the UK are here. See chapter 20:

Under the PSRs 2017, strong customer authentication means authentication based on the use of two or more independent elements (factors) from the following categories:

• something known only to the payment service user (knowledge)

• something held only by the payment service user (possession)

• something inherent to the payment service user (inherence)

So will we see a lot more card readers and token devices? Maybe not. They offer decent security, but they are expensive, and when users lose them or they wear out or the battery goes, they have to be replaced, which means more admin and expense. Giant companies like security, but they care almost as much about keeping costs down and automating password reset and account recovery.

Instead, the favoured approach is to use your mobile phone. There are several ways to do this, of which the simplest is where you are sent a one-time code by SMS. Another is where you install an app that generates codes, just like the key fob devices, but with support for multiple accounts and no need to clutter up your pocket or bag.

These are not bad solutions – some better than others – but this is a system, remember. It used to be your email address, but now it is your phone and/or your phone number that is critical to your security. All of us need to think carefully about a couple of things:

– if our phone is lost or broken, can we still get our work done?

– if a bad guy steals our phone or hijacks the number (not that difficult in many cases, via a little social engineering), what are the consequences?

Note that the SCA regulations insist that the factors are each independent of the other, but that can be difficult to achieve. There you are with your authenticator app, your password manager, your web browser with saved usernames and passwords – all on your phone.

Personally I realised recently that I now have about a dozen authenticator accounts on a phone that is quite old and might break; I started going through them and evaluating what would happen if I lost access to the app. Unlike many apps, most authenticator apps (for example those from Google and Microsoft) do not automatically reinstall complete with account data when you get a new phone.

Here are a few observations.

First, SMS codes are relatively easy from a recovery perspective (you just need a new phone with the same number), but not good for security. Simon Thorpe at Authy has a good outline of the issues with it here and concludes:

Essentially SMS is great for finding out your Uber is arriving, or when your restaurant table is ready. But SMS was never designed to provide a secure way for you to login to your online banking account.

Yes, Authy is pitching its alternative solutions but the issues are real. So try to avoid them; though, as Thorpe notes, SMS codes are much stronger security than password alone.

Second, the authenticator app problem. Each of those accounts is actually a long code. So you can back them up by storing the code. However it is not easy to get the code unless you hack your phone, for example getting root access to an Android device.

What you can do though is to use the “manually enter code” option when setting up an account, and copy the code somewhere safe. Yes you are undermining the security, but you can then easily recover the account. Up to you.

If you use the (free) Authy app, the accounts do roam between your various devices. This must mean Authy keeps a copy on its cloud services, hopefully suitably encrypted. So it must be a bit less secure, but it is another solution.

Third, check out the recovery process for those accounts where you rely on your authenticator app or smartphone number. In Google’s case, for example, you can access backup codes – they are in the same place where you set up the authenticator account. These will get you back into your account, once for each code. I highly recommend that you do something to cover yourself against the possibility of losing your authenticator code, as Google is not easy to deal with in account recovery cases.

A password manager or an encrypted device is a good place to store backup codes, or you may have better ideas.

The important thing is this: a smartphone is an easy thing to lose, so it pays to plan ahead.

Wrestling with Visual Basic 6 (really!) and how knowledge on the internet gets harder to find

I have not done a thing with Visual Basic 6 for years, but a contact of mine has done a very useful utility in a certain niche (it is the teaching of Contract Bridge though you do not need to know about bridge to follow this post) and his preferred tools are VBA and Visual Basic 6.

Visual Basic 6 is thoroughly obsolete, but apps compiled with it still run fine on Windows 10 and Microsoft probably knows better than to stop them working. The IDE is painful on versions of Windows later than XP but that is what VMs are for. VBA, which uses essentially the same runtime (though updated and also available in 64-bit)  is not really obsolete at all; it is still the macro language of Office though Microsoft would prefer you to use a modern add-in model that works in the cloud.

Specifically, we thought it would be great to use Bo Haglund’s excellent Double Dummy Solver which is an open source library and runs cross-platform. So it was just a matter of doing a VB6 wrapper to call this DLL.

I did not set my sights high, I just wanted to call one function which looks like this:

EXTERN_C DLLEXPORT int STDCALL CalcDDtablePBN(
   struct ddTableDealPBN tableDealPBN,
   struct ddTableResults * tablep);

and the ddTableResults struct looks like this:

struct ddTableResults
{
   int resTable[DDS_STRAINS][DDS_HANDS];
};

I also forked the source and created a Visual C++ project for it for a familiar debugging experience.

So the first problem I ran into (before I compiled the DLL for myself) is that VB6 struggles with passing a struct (user-defined type or UDT in VB) ByVal. Maybe there is a way to do it, but this was when I ran up Visual C++ and decided to modify the source to make it more VB friendly, creating a version of the function that has pointer arguments so that you can pass the UDT ByRef.

A trivial change, but at this point I discovered that there is some mystery about  __declspec(dllexport) in Visual C++ which is meant to export undecorated functions for use in a DLL but does not always do so. The easy solution is to go back to using a DEF file and after fiddling for a bit I did that.

Now the head-scratching started as the code seemed to run fine but I got the wrong results. My C++ code was OK and the unit test worked perfectly. Further, VB6 did not crash or report any error. Just that the values in the ddTableResults.resTable array after the function returned were wrong.

Of course I searched for help but it is somewhat hard to find help with VB6 and calling DLLs especially since Microsoft has broken the links or otherwise removed all the helpful documents and MSDN articles that existed 20 years ago when VB6 was hot.

I actually dug out my old copy of Daniel Appleman’s Visual Basic Programmer’s Guide to the Windows API where he assured me that arrays in UDTs should work OK, especially since it is just an array of integers rather than strings.

Eventually I noticed what was happening. When I passed my two-dimensional array to the DLL it worked fine but in the DLL the indexes were inverted. So all I needed to do was to fix this up in my wrapper. Then it all worked fine. Who knows what convoluted stuff happens under the surface to give this result – yes I know that VB6 uses SAFEARRAYs.


I do not miss VB6 at all and personally I moved on to VB.NET and C# at the earliest opportunity. I do understand however that some people like to stay with what is familiar, and also that legacy software has to be maintained. It would be interesting to know how many VB6 projects are still being actively maintained; my guess is quite a few. Which if you read Bruce McKinney’s well-argued rants here must be somewhat frustrating.

Microsoft’s Pipelines for Azure Kubernetes Service: fixing COPY failed

I like to try new technology when I can so following the Build conference I decided to deploy a Hello World app to Azure Kubernetes Service (AKS). I made a one-node AKS cluster in no time. I built a .NET Core app in Visual Studio deployed to a Linux Docker container, no problem. I pushed the container into ACR (Azure Container Registry) though it turns out I did not really need to do that. The tricky bit is getting the container deployed to the AKS cluster. There is a thing called Dev Spaces but it does not work in UK South:


I was contemplating the necessity of building a Helm chart when I tried a thing called Deployment Center (Preview) in the Azure portal.

Click Add Project and it builds a pipeline in Azure DevOps for you.


It worked but the pipeline failed when building the container.

COPY failed: stat /var/lib/docker/tmp/docker-builder088029891/AKS-Example/AKS-Example.csproj: no such file or directory

I spent some time puzzling over this error. You can view the exact logs of the build failure and I worked out that it is executing the Dockerfile steps:

COPY [“AKS-Example/AKS-Example.csproj”, “AKS-Example/”]

RUN dotnet restore “AKS-Example/AKS-Example.csproj”
COPY . .

This is failing because there the code in my repository is not nested like that. I eventually fixed it by amending the lines to:

COPY [“AKS-Example.csproj”, “AKS-Example/”]
RUN dotnet restore “AKS-Example/AKS-Example.csproj”

COPY . AKS-Example/

Now the pipeline completed and the container was deployed. I had to look at the Load Balancer Azure had generated for me to find the public IP number, but it worked.


Now the Dockerfile has a different path for local development than when deployed which is annoying. I found I could fix this by changing a step in the Deployment Center wizard:


Where it says /AKS-Example in Docker build context I replaced it with /. Now the build worked with the original Dockerfile.

I also noticed that the Deployment Center (Preview) used a sample YAML template which is linked directly from GitHub and referred confusingly to deploying sampleapp. It worked but felt a bit of a crude solution.

At this point I realised that I was not really using the latest and greatest, which is the pipeline wizard in Azure Devops. So I deleted everything and tried that.


This was great but I could not see an equivalent step to the Docker build context. And indeed, the new build failed with the same COPY failed error I got originally. Luckily I knew the workaround and was up and running in no time.

This different approach also has a slightly different shape than the Deployment Center pipeline, using Environments in Azure DevOps.

Currently therefore I have two questions:

  • Why does Azure offer both the Deployment Center (Preview) and the multi-stage pipeline which seem to have overlapping functionality?
  • What is the correct way to modify the generated YAML to fix the path issue?

I suppose it would also be good if the path problem were picked up by the wizard in the first place.

Automatic transcription for journalists: still not viable despite Microsoft push for “Modern journalism”

I am just back from Microsoft’s developer-focused Build event, where some special sessions were laid on for press, on the subject of “Modern journalism.”

Led by Microsoft’s Ben Rudolph, Modern Journalism is described on his public LinkedIn profile as “a new program committed to helping the news industry fight fake news, tell stories that resonate with modern audiences, and succeed financially.”

The sessions appealed to me for one particular reason, which was the promise of automatic transcription. We were given a leaflet which says:

Tired of digging through hours of recordings to find that one quote? When you record a Teams interview, it’s saved to Microsoft Stream. Here you’ll get game-changing AI features: searchable transcript to jump to exact moments a key word or phrase was used.

Before the transcription thing though, we were taken on a tour of OneNote and Word with AI. The latest AI Editor in Word will tighten up your prose and find gaffes like non-inclusive language. There is lack of clarity over the privacy implications (these features work by uploading everything you type to Microsoft) but perhaps it is useful. I make plenty of typographical errors and would welcome help, though I remain sceptical about the extent to which AI can deliver this.

On to transcription though. Just hit record during a voice or video meeting in Teams, Microsoft’s Office 365 collaboration tool, and it gets automatically transcribed.

Unfortunately I do not use Teams for interviews, though it is possible to use it even for in-person interviews by having a meeting of one and recording it. I am wary though. I normally use an external recording device. Many years ago my device failed one day (I forget whether it was battery or something else) and I used my Tablet PC to record an interview with the game inventor Peter Molyneux. My expectations were not particularly high – I just wanted something good enough that I could transcribe it later. Unfortunately the recording was so poor that you can only make out about one word in ten. This, combined with my written notes and memory, was just about sufficient to write up my piece; but it was not an experiment I felt inclined to repeat – though recording quality has improved since that early disaster.

Still, automatic transcription would be an amazing time-saver. Further, I respect what can be achieved. Nuance Dragon Dictate can give superb results after a bit of training. What about Teams?

Today I put the idea to the test. I took a recorded interview from Build, made with a dedicated device, and uploaded it to Microsoft Stream. I tried uploading an audio file directly, but it would not accept it. I then created a “video” by importing my audio into a one-slide PowerPoint presentation and exporting it as a video. The quality is fine, easily intelligible. Stream chewed on it for maybe 30 minutes, and then my transcript was ready. The subject was the Azure Kubernetes Service. Here is a snippet of what Stream came up with:


There is an unnecessary annoyance here, which is that you cannot easily select and copy the entire transcript. Notice that it is in short snippets. The best way to get the whole thing is to click the three dots under the video, choose Update Video Details, and then download the caption file.


Now you get something like this:


The format is, shall we say, sub-optimal for journalists, though it would not take too long to write a script that would extract the text.

The bigger problem is the actual transcription. The section I have chosen is wrong in an interesting way. Here is part of what was said:

With the KEDA announcement today, what you’re seeing is us working with the ecosystem, in this case Red Hat, to solve some tricky problems around how to autoscale containers.

and here is the transcription:

with
the Kate Announcement. Today, which are seeing is also
actually working with the ecosystem in this case. We had
to sell some tricky problems around how to autoscale containers

Many of the words are correct, but the meaning is scrambled. Red Hat has been transcribed as “we had” losing a critical part of the content.

It is not my intention to rubbish this technology. Automatic transcription is very challenging, especially with specialist content. It is not unreasonable for the system to transcribe KEDA as “Kate”: it is a brand new acronym (Kubernetes-based event-driven autoscaling).

Still, the question I ask myself is whether fixing up the auto transcription will save me any time versus the old-fashioned approach. I use a Word macro that plays back the interview with hot keys to pause and backtrack, editing as I go.

The answer is no. It will take me as long or longer to make sense of the automatic transcription, by comparing it to the original, than to type it from scratch.

This might not always be the case. Perhaps with a more AI-friendly subject the transcription will be good enough to save some time. It could also help to find where in the recording a particular quote appears. So it is not altogether useless.

Transcription is difficult, but there are some simpler matters which Microsoft could improve. Enabling upload of audio files rather than video, and providing a continuous transcript that can easily be copied, for example.

Having a team within Microsoft rooting for journalists strikes me as a good thing in that an internal team may have more influence over the products.

It may be more a matter of some bright spark thinking, hey if we get more journalists using Office 365 that will help to promote the product. A strategy which will be more successful if effort goes into making product fit better with the way journalists actually work.


The future of WPF for developers who need to support Windows 7

If you talk to Microsoft about what is new for Windows Presentation Foundation (WPF), a framework for Windows desktop applications, the answer tends to revolve around the Windows UI Library (WinUI), user interface controls for the Universal Windows Platform and therefore Windows 10, which you can use with WPF. That is no use if you need to compile applications that work on Windows 7. Is WPF on Windows 7 in effect frozen?

Not quite. First, note that WPF (and Windows Forms) was updated for .NET Framework 4.8, with High DPI enhancements and bug fixes. The complete list of fixes is here. So there have been recent updates.

Microsoft says though that .NET Framework 4.8 is the “last major version” of .NET Framework. This suggests that WPF on .NET Framework will not change much in future. WPF is open source; but the open source project targets .NET Core, the cross-platform version of .NET. In addition, there are a few features in WPF for .NET Framework that will never be ported, including XBAPs (XAML Browser Applications) – probably not something you care about.

The good news though is that .NET Core does run on Windows 7 (currently SP1 is required). You can see the progress of WPF on .NET Core here. It is not yet done and there are a few things that will never be supported. But when this is production-ready, it is likely that the open source WPF will run on Windows 7 and thus benefit from any updates and fixes made to the code.

From what I have learned here at Build, Microsoft’s developer conference, it is that .NET Core work that is currently top of mind for the WPF team. This means that WPF on Windows 7 does have a future – provided that .NET Core continues to support Windows 7. This proviso is important, since it is the decision of a different team. At some point there will be a version of .NET Core that does not support Windows 7, and that will be the moment when WPF cannot really progress on that operating system.

There may also be a special case. Presuming Edge Chromium runs on Windows 7, WPF may get a new Edge-based WebView control that runs on Windows 7.

Summary: WPF (and Windows Forms) on .NET Framework is not going to change much in future. If you can transition to using these frameworks on .NET Core though, there is more hope of improvements, though there is no magic that will make Windows 10 features available on Windows 7.

Windows Subsystem for Linux 2: Microsoft’s change of direction delivers better performance, worse integration

It is s feature which most users are not even aware of, but for developers and admins the Windows Subsystem for Linux (WSL) is perhaps the best feature of Windows 10. It gives you seamless access to Linux applications and utilities without needing to run a virtual machine (VM) or remote session. For example, I use it to develop and debug LAMP (Linux, Apache, MySQL, PHP) applications using Visual Studio Code on Windows as the editor. I also use it for running the Let’s Encrypt certbot utility as well as using Linux OpenSSL utilities. It solves Windows annoyances like path limitations and case insensitivity.

Now at the Build developer conference Microsoft has introduced WSL, advertising “dramatic file system performance increases, and full system call compatibility.” That is great, but there is a downside. Unlike the first version, WSL 2 runs in a VM:

WSL 2 uses the latest and greatest in virtualization technology to run its Linux kernel inside of a lightweight utility virtual machine (VM)

says the announcement from Microsoft’s Craig Loewen.

Although Microsoft also says that WSL 2 “still provides the same user experience as in WSL 1,” this is not altogether true. One specific difference is that currently I can run my LAMP application, fire up a Windows browser, navigate to Localhost, and there is my application. In WSL 2, the LAMP application will have a different IP number so this will not work. To be fair, when I discussed this with a member of the team I was told that they are working to address this and tinker with the networking so that localhost will work again. It also arguable that the different IP number is preferable behaviour, since it will not conflict with other endpoints on the Windows side. But it is different.

The use of a VM for WSL 2 is the conventional approach to this problem. In fact, you have been able to run a Linux VM on Windows for many years. The difference is the work Microsoft is doing to provide the fastest possible startup and deep integration with the file system so that it behaves more like the original WSL than like an isolated VM. In other words, the problem of running Linux binaries by redirecting system calls (WSL) has been exchanged for another.


Why the change of direction? There are several reasons.

The first is compatibility. No matter how well WSL worked (and it does work very well), there would always be something that did not work as users attempted to use more and more Linux applications.

Second, performance. Apparently:

Initial tests that we’ve run have WSL 2 running up to 20x faster compared to WSL 1 when unpacking a zipped tarball, and around 2-5x faster when using git clone, npm install and cmake on various projects.

Third, when WSL was first conceived it was intended to work on mobile devices which could not support a VM (maybe this was something to do with Android compatibility efforts on Windows Phone).

Finally, Hyper-V has improved to the extent that running WSL 2 on a VM is more feasible.

It does mean that Microsoft will ship its own (but open source) Linux kernel with Windows and update it via Windows Update, a good thing for security.

The reasons are good ones, but it would not surprise me to see other niggling integration issues. And it is just a little sad that the magic of the original WSL has been replaced by a more conventional approach.

I also feel that if you came to Build looking for support for a narrative that Microsoft is drifting away from Windows and towards Linux, WSL 2 would support that narrative.

One .NET: unification of .NET for Windows and .NET Core, Xamarin too

Microsoft’s forking of the .NET development platform into the Windows-only .NET Framework on one side, and the cross-platform .NET Core on the other, has caused considerable confusion. Which should you target? What is the compatibility story? And where does Mono, the older cross-platform .NET fit in? Xamarin, partly based on Mono, is another piece of the puzzle.

Now Microsoft has announced that .NET 5, coming in November 2020, will unify these diverse .NET versions.

“There will be just one .NET going forward, and you will be able to use it to target Windows, Linux, macOS, iOS, Android, tvOS, watchOS and WebAssembly and more,” says Microsoft’s Rich Turner.


Following the release of .NET 5.0, the framework will have a major release every November, says Turner, with a long-term support release every two years.

Some other key announcements:

  • CoreCLR (the .NET Core runtime) and Mono will become drop-in replacements for one another.
  • Java interoperability will be available on all platforms.
  • Objective-C and Swift interoperability will be supported on multiple operating systems.
  • CoreFX will be extended to support static compilation of .NET and support for more operating systems.

A note of caution though. Turner says there are a number of issues still to be resolved. There is room for scepticism about how complete this unification will be.

More details in the official announcement here.

Update: having looked at these plans in a little more detail, it is wrong to say that Microsoft is unifying .NET Framework and .NET Core. Rather, Microsoft is saying that .NET Core is the replacement for .NET Framework for new applications whether on Windows or elsewhere. Certain parts of .NET Framework, including WCF, Web Forms, and Windows Workflow, will never be migrated to .NET 5. .NET Framework 4.8 will still be maintained and is recommended for existing applications.

Microsoft Build and the repositioning of Windows

Microsoft Build is under way in Seattle, with around 6000 attendees here to learn about the company’s latest developer technology. But what is the heart of Microsoft’s platform today? The answer used to be Windows – and this conference was originally the Build Windows event, distinct from the earlier Professional Developer Conference which was run by the Developer Division and had a wider scope.

Microsoft’s Satya Nadella introduces Build 2019

  Today though it is not so clear. The draft Build 2019 press release hardly mentions Windows. Here is the summary of topics:

In his opening keynote, Microsoft CEO Satya Nadella outlined the company vision and developer opportunity across Microsoft Azure, Microsoft Dynamics 365 and Power Platform, Microsoft 365, and Microsoft Gaming”

Windows is there of course. Azure uses Hyper-V, the Windows Server hypervisor. A Microsoft 365 license is a bundle of Office 365, InTune device management, and Windows Enterprise. Microsoft Gaming includes PC gaming, and Xbox gets its name from the Windows DirectX hardware accelerated graphics API. But no, this is no longer a conference about developing for Windows, and Microsoft seems happy for its operating system to be less visible. PCs remain the devices on which many of us get most of our work done, but it is not a growth market, and cannot really become one unless by some miracle Microsoft returned to mobile or wearables. That would be hard, especially since the Universal Windows Platform, originally conceived as an app platform for touch and mobile as well as desktop, has drifted away from that concept and become something of uncertain relevance unless you are targeting HoloLens or some other niche.

That said, Windows is still evolving and Build remains the best event to keep track of what is new. In the advance news on which this post is based, several key features were announced.

Windows Subsystem for Linux 2 (WSL) now supports Linux Docker containers as well as faster file I/O. This also integrates nicely with new Visual Studio Code Remote Development Extensions which let you edit and debug code in WSL, in Docker containers, or on any remove machine over SSH.

Windows Terminal is a new application for command lines including PowerShell, Cmd and WSL. It includes rich fonts (with hardware accelerated rendering), multiple tabs, and “theming and customization”.

React Native for Windows is an open source project on GitHub that will let you develop high performance Windows applications.

MSIX Core is the next step in Windows setup technology and lets you install MSIX packages on Windows 7 as well as Windows 10.

.NET 5 has been announced and seems to embrace both Windows Desktop and cross-platform – I will be unpacking the details of how this works shortly. .NET 5 will release in 2020.

Microsoft Edge (on Chromium) has new features announced included an IE mode tab (for running Internet Explorer applications/sites), three levels of privacy (Unrestricted, Balanced and Strict) which claim to control third-party tracking, and Collections which is a feature for collecting and sharing web information and integrates with Office.

Of course there is much more news on what Microsoft now sees as its top priority topics: Azure, AI, Microsoft Search, PowerApps, PowerBI, Cognitive Services, Bot Framework, Mixed reality, IoT and Edge computing, Cosmos DB, Azure Kubernetes Service, GitHub and more.

Windows? Still the best way to run Office, and excellent for developing applications. But this is Microsoft Build, not Build Windows.

Seattle, Washington the evening before Microsoft Build

Microsoft Office and privacy: happy to send what you type to the cloud for analysis?

I attempted to open a document from on-premises SharePoint recently and was greeted with an error asking me to check my privacy settings.


“The service required to use this feature is turned off” I was informed. Hmm, what service is that then? The solution turned out to be in the new Office privacy settings, just as the dialog suggested.

If you disable what Microsoft calls “Connected experiences” it appears to block access to SharePoint. Probably not what the user intended.


This setting is not great for clarity. Privacy-conscious users like myself may disable it because it represents your agreement to “experiences that analyze your content”. Since this means uploading your content to the cloud for analysis it sounds as if it might weaken both privacy and security. If you look at all the options though, it may be possible to agree to access online file storage without agreeing to content analysis:


It looks as if by unchecking “Let Office analyze your content” you might be able to stop Office uploading your stuff.

Is there anything to worry about? We need to know more about what happens to our data. There is a Learn More link that takes us here. This lists lots of features but does not tell us what we want to know. Maybe here? This tell us that:

Three types of information make up required service data.

  • Customer content, which is content you create using Office, such as text typed in a Word document, and is used in conjunction with the connected experience.

It is still not clear though what happens to our data, other than that it is “sent to Microsoft”. Even the massive Microsoft Privacy Statement is no more illuminating on this point. In fact, it is arguably rather alarming since it contains this statement:

Microsoft uses the data we collect to provide you with rich, interactive experiences. In particular, we use data to:

  • Provide our products, which includes updating, securing, and troubleshooting, as well as providing support. It also includes sharing data, when it is required to provide the service or carry out the transactions you request.
  • Improve and develop our products.
  • Personalize our products and make recommendations.
  • Advertise and market to you, which includes sending promotional communications, targeting advertising, and presenting you with relevant offers.

We also use the data to operate our business, which includes analyzing our performance, meeting our legal obligations, developing our workforce, and doing research.

In carrying out these purposes, we combine data we collect from different contexts (for example, from your use of two Microsoft products) or obtain from third parties to give you a more seamless, consistent, and personalized experience, to make informed business decisions, and for other legitimate purposes.

This suggests that Microsoft will profile me and send me advertising based on the data it collects. What I need to know is not only the fact that this happens, but also the mechanism, in order to make an informed judgement about whether it is sensible to enable these options. Of course it is also possible that the Office content analysis service does not do this. I am guessing.

What can go wrong? These risks are hard to quantify. If you are typing something confidential, it makes sense not to share it more than is necessary, as further sharing can only increase the risk. There are some interesting scenarios too, such as what happens if Microsoft receives a legal demand to have sight of the content of your documents. Microsoft may not want to give access to your content, but in some circumstances it might not have the choice. Then again, I doubt it retains content sent for the purpose of personalisation, beyond whatever factors the service determines are significant. However this is not stated here.

Is this any different from storing documents on a cloud service such as SharePoint / OneDrive online? It is a bit different since in the Office case you are permitting Microsoft to analyze as well as to store your content.

All of this is up for debate. I accept that the risks are probably small as well as the fact that the wider world has little or no interest in most of the content I type but do not choose to publish.

Nevertheless, there are a few things which seem to me reasonable requests.

– A clear statement concerning what happens to my content if I choose to let it be analyzed by Microsoft’s cloud service, to enable better informed decisions about whether or not to enable this feature. Dumping the user into an all-encompassing privacy policy is not good enough.

– Improved settings (and possibly some fixed bugs) so that privacy-conscious users do not inadvertently disable access to on-premises SharePoint, as in my example, or other unexpected outcomes.

– A simple way to exclude a specific document from the service, conceptually similar to “in-private” mode in a web browser though with more chance of actually protecting your privacy (in-private mode is not really very private).

In general, I do not think the solution to a customer’s reasonable concerns about privacy and security of personal information is to obscure how this data is handled.

A post that can save you money: scheduling Azure Virtual Machines for start/stop

I have written recently about Windows Virtual Desktop, the ability to set up a virtual desktop environment on Azure at a relatively low cost, provided your users have Microsoft 365 accounts. My test setup is minimal but I have been watching the cost which is currently working out at £5.39 per day. This excludes the cost of Microsoft 365; it is purely for the infrastructure including VPN gateway, storage and VM. Bandwidth is a variable cost but almost negligible on my usage. Of that cost, the VM is around 75%. So if I could shut down the VM when not in use the savings are substantial.

It turns out this is pretty easy on Azure though it requires some plumbing. VMs do have a built-in option to shutdown on a schedule, but not to start up. To get start/stop, you need an Automation Account.


With the automation account created, select it, hit Start/Stop VM, then click “Learn more about and enable the solution”.  You get this dialog.


Here we learn that to save money, we have to spend it, on three new services: Automation, Log Analytics, and Monitor. It is not too bad though as there is a free tier for these services that may be all I need. Hit Create.


In this window you have to configure three sections. Nothing challenging, but note that in Configuration you set the Target Resource Group Names. No pick list here, you have to type in the names. Or use a wildcard, which is unlikely to be a good idea since by default it will start and stop ALL your VMs. The schedule is not very smart, just a daily on and off, but see below. Once done, click Create to add the solution.

All done, but what about weekends, for example. This is easily fixed if you create your own schedules. Just go into your automation account and click Schedules under Shared Resources. The wizard-created schedules are listed, and you can modify them or create new ones. It looks as if you might need 5 schedules, one per weekday, recur every week, to make your VMs not run at weekends. There is no Monday-Friday option.

More documentation here. Note that automation can also run PowerShell scripts which will be even more flexible.

Scheduling cloud resources to shut down when not in use must be one of the most effective ways to reduce IT spend.

Update: here is the outcome of my efforts:


The Management resource group has the runbook that performs the start/stop action. The cost of this is small. Overall cost has gone down by about £2.00 or about 40% in my case. I appreciate this is a very small test deployment, but it would support maybe 4 or 5 users without any problem and my experience shows that you can indeed make a large saving by scheduling VMs to stop when not in use.
