Category Archives: microsoft

Microsoft Office 365 and Google G-Suite: why multi-factor authentication is now essential

Businesses using Office 365, Google G-Suite or other hosted environments (but especially Microsoft and Google) are vulnerable to phishing attacks that steal user credentials. Here is a recent example, which sailed through Microsoft’s spam and malware filters despite its attempts to use AI and other techniques to catch them.


If a user clicks the link and signs in, the bad guys have their credentials. What are the consequences?

– at best, a bunch of spam sent out from the user’s account, causing embarrassment and a quick password reset.

– at worst, something much more serious. Once an unauthorised party has user credentials, there are all sorts of social engineering possibilities to escalate the attack, obtain other credentials, or see what interesting data can be found in collaborative document stores and shared applications.

– another risk is to discover information about an organisation’s customers and contact them to advise of new bank details which of course direct payments to the attacker’s account.

The truth is there are many risks and it is worth every effort to prevent this happening in the first place.

However, it is hard to educate every user to the extent that you can be confident they will never click a link in an email such as the one above, or reveal their password in some other way – such as using the same one as one that has been leaked – check here to find out, for example.

Multi-factor authentication (MFA), which is now easy to set up on both Office 365 or G-Suite, helps matters by requiring users to enter a one-time code from their mobile, either via an authenticator app or a text message, before they can log in. It does not cost any extra and now is the time to set it up, if you have not already.

It seems to me that in some ways the prevalence of a few big providers in hosted email and applications has made matters easier for the hackers. They know that a phishing attack simulating, say, Office 365 support will find many potential victims.

The more positive view is that even small businesses can now easily use Enterprise-grade security, if they choose to take advantage.

I do not think MFA is perfect. It usually depends on a mobile phone, and given that possession of a user’s phone also often enables you to reset the password, there is a risk that the mobile becomes the weak link. It is well known that social engineering against mobile providers can persuade them to cancel a SIM and issue a new one to an impostor.

That said, hijacking a phone is a lot more effort than sending out a million phishing emails, and on balance enabling MFA is well worth it.

Want to connect PowerBI to Dynamics 365 CRM on-premises? Good luck with the official documentation

Microsoft champions hybrid IT, that is, some IT on-premises, some in the cloud; but its cloud-first strategy means that on-premises customers sometimes have a hard time getting the most from their software.

I have posted before about Dynamics CRM, which is very expensive but in places oddly sloppy, as if Microsoft has quality control issues or just does not care about some of the details in the product.

I encountered another example of this when attempting to configure Power BI desktop to connect to an on-premises instance of Dynamics CRM. At one time this was not supported, but it is now possible using OAuth to authenticate (presuming you have an internet-facing CRM deployment, which is generally the case).

There is an official document explaining how to set this up here.

That said, it seems that whoever wrote the document did not follow through the steps to check that they work, because they do not.

The first error is in in the documentation for enabling OAuth, which tells you to use ClaimsSettings in PowerShell:


However this is not the right setting, and the steps given will give you an error. The correct setting is called OAuthClaimsSettings. It is disabled by default. Set it to enabled using similar steps to those above.

Second, the document tells you to run the Add-Adfsclient command “on the PC where you are running Power BI Desktop”. In fact this must be run on the server where ADFS is installed.

The command itself is not all that reassuring:

Add-AdfsClient -ClientId “a672d62c-fc7b-4e81-a576-e60dc46e951d” -Name “Microsoft Power BI” -RedirectUri @(“https://de-users-preview.sqlazurelabs.com/account/reply/”, “https://preview.powerbi.com/views/oauthredirect.html”) -Description “ADFS OAuth 2.0 client for Microsoft Power BI”

Note the word “preview” that appears a couple of times in this mysterious command.

Even if you do all this, many people have struggled with connection issues. For myself, when I got this working on a test setup, I still got the error:

OData: The feed’s metadata document appears to be invalid. Error: The metadata document could not be read from the message content.

The fix in my case was to use “https://orgname.yourdomain/XRMServices/2011/Organizationdata.svc” for the feed, instead of “https://orgname.yourdomain/api/data/v8.2/”. Then I was up and running.


Maybe someone just needs to tell Microsoft to fix its documentation? A good point, but Cobalt’s Chris Capistran pointed out the errors back in April and nothing has changed.

Of course this sort of thing is not all bad for Microsoft partners, who can come in with superior knowledge and get things working.

Windows Server 2019 Essentials may be Microsoft’s last server offering for small businesses

Microsoft’s Windows Server Team has posted about Windows Server 2019 Essentials, stating that:

“There is a strong possibility that this could be the last edition of Windows Server Essentials.”

Server Essentials is an edition aimed at small organisations that includes 25 Client Access Licenses (CALs). If you go beyond that you have to upgrade to Windows Server Standard at a much higher cost. There are some restrictions in the product, such as lack of support for Remote Desktop Services (other than for admin use).


Microsoft has already greatly reduced its server offering for small businesses. Small Business Server, the last version of which was Windows Small Business Server 2011, bundled Exchange, SharePoint and System Update Services, and supported up to 75 users.

“Capabilities that small businesses need, like file sharing and collaboration are best achieved with a cloud service like Microsoft 365,” says the team, though also observing that Server 2019 will be supported according to the normal timeline, which means you will get something like mainstream support until 2024 and extended support until 2029 or so.

Good decision? There are several ways to look at this. Microsoft’s desire for small businesses to adopt cloud is not without self-interest. The subscription model is great for vendors, giving them a consistent flow of income and a vehicle for upselling.

Cloud also has specific benefits for small businesses. Letting Microsoft manage your email server makes huge sense, for example. The cloud model has brought many enterprise-grade features to organisations which would otherwise lack them.

Despite that, I do not altogether buy the “cloud is always best” idea. From a technical point of view, running stuff locally is more efficient, and from a business point of view, it can be cheaper. Of course there is also a legacy factor, as many applications are designed to run on a server on the local network.

Businesses do have a choice though. Linux works well as a file and print server, and pretty well as a Windows domain controller.

Network attached storage (NAS) devices like those from Synology and Qnap are easy to manage and include a bunch of features which are small-business friendly, including directory services and even mail servers if you still want to do that.

A common problem though with small businesses and on-premises servers (whether Windows or Linux) is weak backup. It makes sense to use the cloud for that, if nothing else.

Although it is tempting to rail at Microsoft for pulling the rug from under small businesses with their own servers, the truth is that cloud does mostly make better sense for them, especially with the NAS fallback for local file sharing.

Where next for Windows Mixed Reality? At IFA, Acer has an upgraded headset at IFA; Dell is showing Oculus Rift

It is classic Microsoft. Launch something before it is ready, then struggle to persuade the market to take a second look after it is fixed.

This may prove to be the Windows Mixed Reality story. At IFA in Berlin last year, all the major Windows PC vendors seemed to have headsets to show and talked it up in their press events. This year, Acer has a nice new generation headset, but Asus made no mention of upgrading its hardware. Dell is showing Oculus Rift on its stand, and apparently is having an internal debate about future Mixed Reality hardware.

I reviewed Acer’s first headset and the technology in general late last year. The main problem was lack of content. In particular, the Steam VR compatibility was in preview and not very good.

Today I tried the new headset briefly at the Acer booth.


The good news: it is a big improvement. It feels less bulky but well made, and has integrated headphones. It felt comfortable even over glasses.

On the software side, I played a short Halo demo. The demo begins with a promising encounter with visceral Halo aliens, but becomes a rather dull shooting game. Still, even the intro shows what is possible.

I was assured that Steam VR compatibility is now much improved, but would like to try for myself.

The big questions are twofold. Will VR really take off at all, and if it does, will anyone use Windows Mixed Reality?

SQLite with .NET: excellent but some oddities

I have been porting a C# application which uses an MDB database (the old Access/JET format) to one that uses SQLite. The process has been relatively smooth, but I encountered a few oddities.

One is puzzling and is described by another user here. If you have a column that normally stores string values, but insert a string that happens to be numeric such as “12345”, then you get an invalid cast exception from the GetString method of the SQLite DataReader. The odd thing is that the GetFieldType method correctly returns String. You can overcome this by using GetValue and casting the result to a string, or calling GetString() on the result as in dr.GetValue().ToString().

Another strange one is date comparisons. In my case the application only stores dates, not times; but SQLite using the .NET provider stores the values as DateTime strings. The SQLite query engine returns false if you test whether “yyyy-mm-dd 00:00:00” is equal to “yyy-mm-dd”. The solution is to use the date function: date(datefield) = date(datevalue) works as you would expect. Alternatively you can test for a value between two dates, such as more than yesterday and less than tomorrow.

Performance is excellent, with SQLite . Unit tests of various parts of the application that make use of the database showed speed-ups of between 2 and 3 times faster then JET on average; one was 8 times faster. Note though that you must use transactions with SQLite (or disable synchronous operation) for bulk updates, otherwise database writes are very slow. The reason is that SQLite wraps every INSERT or UPDATE in a transaction by default. So you get the effect described here:

Actually, SQLite will easily do 50,000 or more INSERT statements per second on an average desktop computer. But it will only do a few dozen transactions per second. Transaction speed is limited by the rotational speed of your disk drive. A transaction normally requires two complete rotations of the disk platter, which on a 7200RPM disk drive limits you to about 60 transactions per second.

Without a transaction, a unit test that does a bulk insert, for example, took 3 minutes, versus 6 seconds for JET. Refactoring into several transactions reduced the SQLite time to 3 seconds, while JET went down to 5 seconds.

Should you convert your Visual Basic .NET project to C#? Why and why not…

When Microsoft first started talking about Roslyn, the .NET compiler platform, one of the features described was the ability to take some Visual Basic code and “paste as C#”, or vice versa.

Some years later, I wondered how easy it is to convert a VB project to C# using Roslyn. The SharpDevelop team has a nice tool for this, CodeConverter, which promises to “Convert code from C# to VB.NET and vice versa using Roslyn”. You can also find this on the Visual Studio marketplace. I installed it to try out.


Why would you do this though? There are several reasons, the foremost of which is cross-platform support. The Xamarin framework can use VB to some extent, but it is primarily a C# framework. .NET Core was developed first for C#. Microsoft has stated that “with regard to the cloud and mobile, development beyond Visual Studio on Windows and for non-Windows platforms, and bleeding edge technologies we are leading with C#.”

Note though that Visual Basic is still under active development and history suggests that your Windows VB.NET project will continue running almost forever (in IT terms that is). Even Visual Basic 6.0 applications still run, though you might find it convenient to keep an old version of Windows running for the IDE.

Still, if converting a project is just a right-click in Visual Studio, you might as well do it, right?


I tried it, on a moderately-size VB DLL project. Based on my experience, I advise caution – though acknowledging that the converter does an amazing job, and is free and open source. There were thousands of errors which will take several days of effort to fix, and the generated code is not as elegant as code written for C#. In fact, I was surprised at how many things went wrong. Here are some of the issues:

The tool makes use of the Microsoft.VisualBasic namespace to simplify the conversion. This namespace provides handy VB features like DateDiff, which calculates the difference between two dates. The generated project failed to set a reference to this assembly, generating lots of errors about unknown objects called Information, Strings and so on. This is quick to fix. Less good is that statements using this assembly tend to be more convoluted, making maintenance harder. You can often simplify the code and remove the reference; but of course you might introduce a bug with careless typing. It is probably a good idea to remove this dependency, but it is not a problem if you want the quickest possible port.

Moving from a case-insensitive language to a case-sensitive language is a problem. Visual Studio does a good job of making your VB code mostly consistent with regard to case, but that is not a fix. The converter was unable to fix case-sensitivity issues, and introduced some of its own (Imports System.Text became using System.text and threw an error). There were problems with inheritance, and even subtle bugs. Consider the following, admittedly ugly and contrived, code:


Here, the VB coder has used different case for a parameter and for referencing the parameter in the body of the method. Unfortunately another variable with the different case is also accessible. The VB code and the converted C# code both compile but return different results. Incidentally, the VB editor will work very hard to prevent you writing this code! However it does illustrate the kind of thing that can go wrong and similar issues can arise in less contrived cases.

C# is more strict than VB which causes errors in conversion. In most cases this is not a bad thing, but can cause headaches. For example, VB will let you pass object members ByRef but C# will not. In fact, VB will let you pass anything ByRef, even literal values, which is a puzzle! So this compiles and runs:


Another example is that in VB you can use an existing variable as the iteration variable, but in C# foreach you cannot.

Collections often go wrong. In VB you use an Item property to access the members of a collection like a DataReader. In C# this is omitted, but the converter does not pick this up.

Overloading sometimes goes wrong. The converter does not always successfully convert overloaded methods. Sometimes parameters get stripped away and a spurious new modifier is added.

Bitwise operators are not correctly converted.

VB allows indexed properties and properties with parameters. C# does not. The converter simply strips out the parameters so you need to fix this by hand. See https://stackoverflow.com/questions/2806894/why-c-sharp-doesnt-implement-indexed-properties if the language choices interest you.

There is more, but the above gives some idea about why this kind of conversion may not be straightforward.

It is probably true that the higher the standard of coding in the original project, the more straightforward the conversion is likely to be, the caveat being that more advanced language features are perhaps more likely to go wrong.

Null strings behave differently

Another oddity is that VB treats a String set to null (Nothing) as equivalent to an empty string:

Dim s As String = Nothing

If (s = String.Empty) Then ‘TRUE in VB
     MsgBox(“TRUE!”)
End If

C# does not:

String s = null;

   if (s == String.Empty) //FALSE in C#
    {
        //won’t run
    }

Same code, different result, which can have unfortunate consequences.

Worth it?

So is it worth it? It depends on the rationale. If you do not need cross-platform, it is doubtful. The VB code will continue to work fine, and you can always add C# projects to a VB solution if you want to write most new code in C#.

If you do need to move outside Windows though, conversion is worthwhile, and automated conversion will save you a ton of manual work even if you have to fix up some errors.

There are two things to bear in mind though.

First, have lots of unit tests. Strange things can happen when you port from one language to another. Porting a project well covered by tests is much safer.

Second, be prepared for lots of refactoring after the conversion. Aim to get rid of the Microsoft.VisualBasic dependency, and use the stricter standards of C# as an opportunity to improve the code.

Microsoft’s Dynamics CRM 2016/365: part brilliant, part perplexing, part downright sloppy

I have just completed a test installation of Microsoft’s Dynamics CRM on-premises; it is now called Dynamics 365 but the name change is cosmetic, and in fact you begin by installing Dynamics CRM 2016 and it becomes Dynamics 365 after applying a downloaded update.

Microsoft’s Dynamics product has several characteristics:

1. It is fantastically useful if you need the features it offers

2. It is fantastically expensive for reasons I have never understood (other than, “because they can”)

3. It is tiresome to install and maintain

I wondered if the third characteristic had improved since I last did a Dynamics CRM installation, but I feel it has not much changed. Actually the installation went pretty much as planned, though it remains fiddly, but I wasted considerable time setting up email synchronization with Exchange (also on-premises). This is a newish feature called Server-Side Synchronization, which replaces the old Email Router (which still exists but is deprecated). I have little love for the Email Router, which when anything goes wrong, fills the event log with huge numbers of identical errors such that you have to disable it before you can discover what is really going wrong.

Email is an important feature as automated emails are essential to most CRM systems. The way the Server-Side Synchronization works is that you configure it, but CRM mailboxes are disabled until you complete a “Test and Enable” step that sends and receives test emails. I kept getting failures. I tried every permutation I could think of:

  • Credentials set per-user
  • Credentials set in the server profile (uses Exchange Impersonation to operate on behalf of each user)
  • Windows authentication (only works with Impersonation)
  • Basic authentication enabled on Exchange Web Services (EWS)

All failed, the most common error being “Http server returned 401 Unauthorized exception.” The troubleshooting steps here say to check that the email address of the user matches that of the mailbox; of course it did.

An annoyance is that on my system the Test and Enable step does not always work (in other words, it is not even tried). If I click Test and Enable in the Mailbox configuration window, I get this dialog:


However if I click OK, nothing happens and the dialog stays. If I click Cancel nothing happens and the dialog stays. If I click X the dialog closes but the test is not carried out.

Fortunately, you can also access Test and Enable from the Mailbox list (select a mailbox and it appears in the ribbon). A slightly different dialog appears and it works.

I was about to give up. I set Windows authentication in the server profile, which is probably the best option for most on-premises setups, and tried the test one more time. It worked. I do not know what changed. As this tech note (which is about server-side synchronization using Exchange Online) remarks:

If you get it right, you will hear Microsoft Angels singing

But what’s this about sloppy? There is plenty of evidence. Things like the non-functioning dialog mentioned above. Things like the date which shows for a mailbox that has not been tested:


Or leaving aside the email configuration, things like the way you can upload Word templates for use in processes, but cannot easily download them (you can use a tool like the third-party XRMToolbox).

And the script error dialog which has not changed for a decade.

Or the warning you get when viewing a report in Microsoft Edge, that the browser is not supported:


so you click the link and it says Edge is supported.

Or even the fact that whenever you log on you get this pesky dialog:


So you click Don’t show this again, but it always reappears.

It seems as if Microsoft does not care much about the fit and finish of Dynamics CRM.

So why do people persevere – in fact, the Dynamics business is growing for Microsoft, largely because of Dynamics 365 online and its integration with Office 365. The cloud is one reason, which removes at least some of the admin burden. The other thing though is that it does bring together a set of features that make it invaluable to many businesses. You can use it not only for sales and marketing, but for service case management, quotes, orders and invoices.

It is highly customizable, which is a mixed blessing as your CRM installation becomes increasingly non-standard, but does mean that most things can be done with sufficient effort.

In the end, it is all about automation, and can work like magic with the right carefully designed custom processes.

With all those things to commend it, it would pay Microsoft to work at making the user interface less annoying and the administration less prone to perplexing errors.

All the way from 1997: Compaq PC Companion C140 still works, but as badly as it did on launch

I am having a clear-out which is bringing back memories and unearthing some intriguing items. One is this Compaq C140 PC Companion, running Windows CE, which launched in December 1997.


The beauty of this device is that it takes two AA batteries. I stuck in some new ones and found that it started up fine, not bad after more than 20 years. Most more recent devices have a non-replaceable rechargeable battery which usually fails long before the rest of the electronics, rendering the entire device useless (at least without surgery).

The C140 runs Windows CE 1.0 and has a monochrome touch screen designed to be used mainly with a stylus. 4MB RAM, 4MB storage, and comes with versions of Word, Excel, Calendar, Contacts and Tasks. There is also a calculator and a world clock. It is expandable with PCMCIA cards (though not many have drivers). The idea is that you link it to your PC with the supplied serial cable and synch with Outlook, hence PC Companion.

The odd thing is, looking at this device I still find it superficially compelling. A pocketable device running Word and Excel, with a full QWERTY keyboard, stylus holder so you do not lose it, what’s not to like?

A lot, unfortunately. The biggest problem is the screen. There is a backlight and a contrast dial, but it is faint and hard to read in most lights and you constantly fiddle with the contrast.

The next issue is the keyboard. It is too cramped to type comfortably. And the format, though it looks reassuringly like a small laptop, is actually awkward to use. It works on a desk, which seems to miss the point, but handheld it is useless. You need three hands, one for the device, one for the stylus, and a third for typing. The design is just wrong and has not been thought through.

I have searched for years for small portable devices with fast text input. I suppose a smartphone with a Swype keyboard or similar comes closest but I am still more productive with a laptop and in practice the thing that has made most improvement for me is that laptops have become lighter and with longer battery life.

Spare a thought though for Microsoft (and its partners) with its long history of trying to make mobile work. You can argue back and forth about whether it was right to abandon Windows Phone, but whatever your views, it is a shame that decades of effort ended that way.

Configuring the Android emulator for Hyper-V

Great news that the Android emulator now supports Hyper-V, but how do you enable it?

Pretty simple. First, you have to be running at least Windows 10 1803 (April 2018 update). Then, go into Control Panel – Programs – Turn Windows Features on and off and enabled both Hyper-V and the Windows Hypervisor Platform:


Note: this is not the same as just enabling Hyper-V. The Windows Hypervisor Platform, or WHPX, is an API for Hyper-V. Read about it here.

Reboot if necessary and run the emulator.


TroubleshootIng? Try running the emulator from the command line.

emulator -list-avds

will list your AVDs.

emulator @avdname -qemu -enable-whpx

will run the AVD called avdname using WHPX (Windows Hypervisor Platform). If it fails, you may get a helpful error message.

Note: If you get a Qt library not found error, use the full path to the emulator executable. This should be the one in the emulator folder, not the one in the tools folder. The full command is:

[path-to-android-sdk]\emulator\emulator @[avdname] -qemu -enable-whpx

You can also use the emulator from Visual Studio, though you need Visual Studio 2017 version 15.8 Preview 1 or higher with the Xamarin tools installed. That said, I had some success with starting the Hyper-V emulator separately (use the command above), then using it with a Xamarin project in Visual Studio 15.7.5.


Microsoft announces free version of Teams, ahead of Inspire partner conference

Microsoft’s partner conference, Inspire, kicks off in Las Vegas next week; and as part of the event the company has announced big news concerning Teams: a free version.


What is Teams? It is a collaboration tool for Office 365, or at least it was, since the new free version can be used with any email address and without Office 365. Here is what you get:

  • Chat
  • Audio and video calling
  • 10GB online storage, plus 2GB for each additional team member (SharePoint/OneDrive)
  • Word, Excel and PowerPoint online
  • Ability to install unlimited additional applications

Teams is a strategic product for Microsoft – see here for the reason. A free version is way for the company to promote Office 365, and you will see an upgrade link in the user interface.

There are also new features coming to Teams. One seems minor, but will be popular. It deals with the problem of video conferencing from home, and not being sure what may happen behind you. You may remember this:


So now Teams video conferencing will let you blur the background. Here is Raanah Amjadi, Marketing Manager, Microsoft Teams, demonstrating the feature:


In addition, Teams is getting a new Live Events feature. This is where you broadcast a presentation or meeting to others in your company. Automatic speech-to-text will do close captions (so you can watch with the sound done, if you trust it enough), and this then enables text search of the event with index points into the video. Bing Translate is also included in Teams so you can have multi-lingual conversations.


Microsoft Workplace Analytics is getting enhancements including “My Analytics” which will give you AI-powered “nudges” in Outlook online. I am not sure I trust this to be much real-world use; but the example shown was intriguing: alert you if you try to schedule a meeting with someone out of their working hours.

Whiteboard, a collaboration canvas, is now generally available for Windows 10 and mobile.


Free Teams is available immediately here.
